Luckfox Lyra PLC Runs Linux on RK3506B with Dual 100Mbps Ethernet
Quoting: Luckfox Lyra PLC Runs Linux on RK3506B with Dual 100Mbps Ethernet —
The Luckfox Lyra PLC is a compact Linux-based programmable logic controller built around the Rockchip RK3506B processor. The DIN-rail system provides dual 100Mbps Ethernet, Wi-Fi 6, Bluetooth 5.2, industrial serial interfaces, CAN, relay outputs, and a 1.9-inch touchscreen.
The RK3506B integrates three Arm Cortex-A7 cores operating at up to 1.2GHz. The controller includes 512MB of DDR3L memory and 8GB of onboard eMMC storage.
CNX Software:
-
Luckfox Lyra PLC - A Linux-based Rockchip RK3506B industrial controller with RS232, RS422, RS485, CAN bus, and relays
Luckfox Lyra PLC is a Linux-based programmable logic controller powered by a Rockchip RK3506B tri-core rm Cortex-A7 SoC, equipped with dual Ethernet, WiFi 6 and Bluetooth 5.2 wireless connectivity, a 1.9-inch touchscreen LCD, and a range of I/Os.
The I/Os are mostly exposed through two 11-pole terminal blocks with one RS232, two RS422/RS485, one CAN Bus, and two relays, as well as smaller connectors for I2C, GPIO, and debugging. The system can be powered via USB-C (5V only), terminal block pins supporting 7V-24V DC input, or an optional PoE module.
